Dry Air Technology VAF 12-E High Volume Ventilator
The VAF-12E is a high-volume ventilator widely used for confined space ventilation, positive and negative air set-up, spot cooling, and exhausting fumes and dust. It is a practical choice for restoration technicians, flood work, and commercial jobs where you need to move a large volume of air or duct it into hard-to-reach spaces.
Compared to heavier metal fans, the VAF-12E is lightweight and portable, making it easier to carry between jobs. Its heavy-duty polyethylene housing is virtually indestructible, so it stands up to the knocks of daily site work.
Key Features
- Large duct rings for a more secure duct fit
- True 12-inch (300mm) fan blade
- Capacity to connect up to 50 metres of 12-inch duct
- Interlocking ribs for stacking vertically
- Durable, lightweight polyethylene housing
- Totally enclosed, energy efficient, high-performing motor
- Designed for easy maintenance
Ducted Ventilation and Air Movement
With the capacity to run up to 50 metres of 12-inch duct, the VAF-12E lets you push clean air into or pull stale air out of confined and hard-to-dry areas. The large duct rings give a secure fit on both the intake and outlet sides, so you can set up positive or negative pressure and keep air moving where you need it.
Built for the Job Site
The totally enclosed motor and rugged polyethylene housing are built to handle demanding restoration and industrial environments. Interlocking ribs let you stack units vertically for transport and storage, and the design keeps routine maintenance simple.
Specifications
- Fan blade: true 12-inch (300mm)
- Motor: 1 HP (approx. 0.75kW), totally enclosed, energy efficient
- Power: 230V / 50Hz (Australian specification)
- Ducting: connects up to 50 metres of 12-inch duct; large duct rings both sides
- Housing: durable, lightweight polyethylene
- Stacking: interlocking ribs for vertical stacking
